DSHY2001-I Automatic distillation test device for petroleum products

Price:	1.0~100.0 USD
Payment Terms:	T/T,L/C,
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean,

Delivery Date: 7 days

Division of liquid level: 0.1mL

Packing: wooden case

Brand Name: dshing

applies to natural petrol (stable light hydrocarbon), automobile gasoline, aviation gasoline, jet fuel, mineral spirits with special boiling point

A:Applied standards:

GB/T 6536-10, ASTM D86-07

B:Application range:

applies to natural petrol (stable light hydrocarbon), automobile gasoline, aviation gasoline, jet fuel, mineral spirits with special boiling point, naphtha, mineral petroleum, kerosene, diesel, gas oil, distillated fuel and other similar petroleum products.

C:Function Features

— 10.4"touch screen computer with USB and Ethernet
— Windows operation system; distillation application software that can switch between Chinese and English
— Precise monitoring of liquid level in the cylinder with photoelectric sensor and stepper motor,thus the distillation volume can be measured precisely
— Display the distillation process dynamically, and the distillation curve and related parameters on a real-time basis. The heating power can be automatically improved on a real-time basis
— The program can set any measuring point for retrieved volume
— Numerous method files can be set up and called at any time
— Automatic temperature control of cold bath and cylinder batch, which satisfies the test conditions of all categories of petroleum required by the standards
— The highly efficient and environment friendly semiconductor cooling is used
— Automatically determine ending conditions and provide test result for printing
— Dry point can be measured (optional)
— Special petroleum sample including heat conductive oil can be tested
— Precise measurement and calibration of air pressure
— Automatic test of accidental fire, and fire-fighting devices can be equipped (optional)
— The test result is displayed in standard XML format which can be sent to LIMS system of the chemical laboratory

D:Technical Specification

— Power supply: 220±10% VAC, 50±1Hz
— Power: ≤2000W
— Dimension: 525mm (width) * 590mm (depth) *585mm (height) (not including vapor temperature sensor)
— Weight: 80Kg
— Environment temperature: 5~25℃; Environment humidity: 20-90% RH without condensation (25℃)
— Distillation temperature: 0~400℃
— Acceptable room temperature: 0~60℃; accuracy of temperature control: ± 0.1℃
— Cold bath temperature: 0~60℃; accuracy of temperature control: ± 0.1℃
— Division of liquid level: 0.1mL
