DSHY2002-I Automatic saturated vapor pressure tester (Reid method) manufacturer from China Zhuhai Dshing Import&Export Co.,ltd

DSHY2002-I Automatic saturated vapor pressure tester (Reid method)

Price:	1.0~100.0 USD
Payment Terms:	T/T,L/C,
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean,

Delivery Date: 7 days

Mercury differential manometer: optional 760mmHg

Packing: wooden case

Brand Name: dshing

determination of saturated vapor pressure of volatile crude oil and other petroleum products

A: Applied standards: ASTM D323, GB/T8017, ISO 3007

B: Application range: determination of saturated vapor pressure of volatile crude oil and other petroleum products

C: Function Features:

—8"color touch screen with beautiful interface and easy operation
— Three single-opening stainless steel bombs which can automatically turn 350°horizontally and change direction automatically
— Real-time display of test curve and automatically determine test result
— 500 records can be stored for search and print at any time
— Precision pressure meter is equipped as a standard and mercury differential manometer is an option for easy pressure correction at any time
— The equipment is equipped with 1L test container according to test standards for easy sample taking and rigorous testing
— Patented rotation mechanism which has taken leakage during water bath and vapor influences into consideration
— PID temperature control system and temperature correction function
— Key components including pressure sensor, electromagnetic valve and motor are imported and highly reliable
— Liquid level protection system which can protect the instrument and trigger an alarm automatically at low level
— RS232 port for connection with LIMS system of the chemical laboratory

D: Technical Specification

—Power supply: 220±10% VAC, 50±1Hz
— Power: ≤1600W
— Dimension: 880mm (width) * 440mm (depth) * 560mm (height)
— Weight: 50Kg
— Environment temperature: 5~35℃; environment humidity: 20-90% RH without condensation (35℃)
— Test range: 0~180 kPa; record accuracy: ±0.1kPa
— Vibration method: 350°horizontal rotation
— Test container: 1L
— Precision pressure meter: 0~200KP, accuracy 0.25 class
— Pressure sensor: 0~200KPa, accuracy 0.2%
— Mercury differential manometer: optional 760mmHg
— Type of bomb: single opening, stainless steel
— Accuracy of temperature control:37.8±0.1℃
